Malaguti Password 250 i.e. - Taillight

91
A
FRAME AND RUNNING GEAR
DISASSEMBLY
11/06
PASSWORD 250 i.e. 5
A
B
A
TAILLIGHT
See “Replacing the taillight bulb” (page 44)
To remove the complete unit first free the
electrical cables from cable tie (A); now de-
tach connector (B) located under the pillion
grab handle (see “Pillion grab handle”).
ACCESSIBILITY
Removing the taillight provides access to the following
components:
• Number plate light connectors (A).
