PASSWORD 250 i.e.
FRAME AND RUNNING GEAR
GETTING TO KNOW YOUR SCOOTER
2
2
1
34
A
B
C
3
2
1
6
4 5
HANDLEBAR CONTROLS
RIGHT-HAND CONTROL
1) Counterweight
2) Throttle grip
3) Front brake lever
4) MODE button: selects the various digital instrument
panel functions
A) Emergency switch, engine stop.
Position - Engine start
Position - Engine stop
B) Lights switch:
rh position = off
central position = parking lights and instrument panel
lh position = low beam / high beam
C) Electric starter button.
LEFT-HAND CONTROL
1) High beam flasher lever (passing)
2) Rear brake lever
3) Counterweight
4) Horn button.
5) Turn indicator switch.
6) Lights selector:
high beam
low beam
