30
11/06
A
PASSWORD 250 i.e.
FRAME AND RUNNING GEAR
GETTING TO KNOW YOUR SCOOTER
2
A = 1206 ± 2 mm
A
DIMENSIONAL CHECK OF FRAME
If the scooter has been involved in an accident and you suspect even slight distortion of the frame it is essential to
perform the dimensional checking procedure before any further “repair or set-up” work.
Control dimension (A) must be 1206 mm with a tolerance of ± 2 mm.
Do not attempt to bend the frame to restore the original “A” measurement.
