A
PASSWORD 250 i.e.
FRAME AND RUNNING GEAR
DISASSEMBLY
5
54
11/06
B
A
B
C
A
C
• Grip front fairing (A) and lift the lower part slightly and
disconnect connector (B); now remove the fairing.
When refitting take care not to pinch the
headlight cable.
ACCESSIBILITY
Removing the front fairing provides access to the follow-
ing components:
• Radiator and relative cap (A).
• Fan connector (B).
• Coolant hoses with clamps (C).
