Malaguti Password 250 i.e. - Coolant Expansion Tank

76
A
FRAME AND RUNNING GEAR
DISASSEMBLY
11/06
PASSWORD 250 i.e.5
COOLANT EXPANSION TANK
• (Remove footboard).
DANGER OF BURNS!
Before proceeding, make sure that the cool-
ant temperature is lower than 50°C.
• Undo the radiator cap.
• Place a 2 l recipient under expansion tank (A).
• Open clamp (B) and slide down the hose; now slide out
hose (C); wait for all the coolant to drain out from both
the hose and the tank.
• Undo screws (V3) and remove tank (A).
A
B
C
A
V3
V3
