A
PASSWORD 250 i.e.
FRAME AND RUNNING GEAR
DISASSEMBLY
5
56
11/06
A
D
B
V4
B
V
V4
3,5 ± 10%
FRONT MUDGUARD
• Undo screw (V) and remove nut (D) responsible for
securing hydraulic hose clamp (A).
• Unscrew screws (V4) on the underside of the mudguard.
• Remove the mudguard, sliding it through the fork and
taking care to protect from scratching.
Pay attention to the four bushes (B) located
under the screws.
