Malaguti Password 250 i.e. - Battery (12 V - 12 Ah)

47 11/06
A
FRAME AND RUNNING GEAR
PASSWORD 250 i.e. 4 MAINTENANCE
A
C
B
D
E
V
BATTERY (12V - 12AH)
The battery housing is in the central channel.
INSTALLING THE BATTERY
• Take a fully charged battery;
• apply the adhesive strip supplied with the scooter as
shown in figure, removing the two protective films from
the ends of the adhesive area, as shown by the arrow
in the drawing (A);
• remove the two sponge vibration dampers from the orig-
inal battery you have just removed and apply them to
the new battery. Procure new vibration dampers if nec-
essary;
• remove the 30A main fuse;
• remove the rubber mats (B);
• undo the 4 screws (V); remove the centre partition un-
der the seat (C);
• remove the elastic band (D) and the plastic “BATTERY”
cover (E);
• insert the battery wiring through the rear of the plastic
cover;
