A
PASSWORD 250 i.e.
FRAME AND RUNNING GEAR
DISASSEMBLY
5
66
11/06
C
B
ACCESSIBILITY
Removing the right-hand sub panel provides access to
the following components:
• Seat lock transmission (A).
NOTE If you need to open the helmet compartment
WITHOUT the key, remove rubber protection
(B) and then pull the two control cable
sheaths.
Removing the left-hand sub panel provides access to the
following components:
• Side stand and relative switch (C).
A
