Malaguti Password 250 i.e. - Instrument Panel

A
PASSWORD 250 i.e.
FRAME AND RUNNING GEAR
DISASSEMBLY
5
50 11/06
A
B
B
V4 V4
V
• Remove the handlebar cover (A) upwards complete with
the instrument panel. Take care not to damage
instrument panel connector cable (B).
INSTRUMENT PANEL
• (Remove windshield).
• (Remove upper handlebar cover).
• Detach the connector (B).
• Undo screws (V4) and screw (V) then detach instru-
ment panel from upper handlebar cover.
