Malaguti Password 250 i.e. - ENGINE

110
A
FRAME AND RUNNING GEAR
DISASSEMBLY
11/06
PASSWORD 250 i.e.5
• Disconnect throttle cable (B) from the throttle body.
B
A
V
ENGINE
• (Remove silencer, including collector and
lambda probe).
• (Remove filter box).
Before proceeding with the engine
disassembly operation, prop up the
centre of the frame to prevent the
scooter from falling.
• Disconnect flywheel connectors (A).
• Undo screw (V) and detach the ground cables
from the frame.
• Disconnect all electric connections related to the engine.
