Malaguti Password 250 i.e. - Instrument Panel Windshield

49
A
FRAME AND RUNNING GEAR
PASSWORD 250 i.e. 5
DISASSEMBLY
11/06
INSTRUMENT PANEL WINDSHIELD
• Remove the two covers (A) taking care not to snap off
the tabs holding them in place.
• Undo screws (V4) and remove the windshield.
• Recover the rubber grommets under the screws.
UPPER HANDLEBAR COVER
• Undo screws (V2).
• Undo screws (V4).
V4
V4
A
V2V2
V4
V4
