Malaguti Password 250 i.e. - Lower Fairing

72
A
FRAME AND RUNNING GEAR
DISASSEMBLY
11/06
PASSWORD 250 i.e.5
LOWER FAIRING
• (Remove upper fairing).
• (Remove front half fairings).
• (Remove sub-fairing).
• Remove keyswitch cover (A), rotating it counter-clock-
wise through ¼ of a turn.
• Open the luggage compartment and undo fusebox
screws (V2).
When reassembling note that the LIGHT
BLUE 15A fuse must be uppermost.
A
V2
