A
FRAME AND RUNNING GEAR
DISASSEMBLY
11/06
PASSWORD 250 i.e. 5
• Undo screws (V4).
There is a bushing (C) under each screw
(V4).
The tank support must rest on a rubber SilentBlock (D);
ensure the rubber mount does not fall.
Fit the electrical cable ties under the two rear screws when
refitting the fuel tank.
V4
V4
V4
C
D
