PRODUCT DIMENSIONS
Openings shown are the minimum for closet
doors.
Louvered doors with equivalent air openings
are acceptable.
Additional spacing should be considered for
the ease of installation and servicing.
Additional clearances may be required for
wall, door and floor moldings.
Additional spacing of 1” (2.5 cm) on all sides
of the washer is recommended to reduce
noise transfer.
Companion spacing should also be
considered.
•
•
•
•
•
The standpipe drain requires a minimum
diameter standpipe of 2” (5 cm). The minimum
carry-away capacity can be no less than 17
gal. (64 L) per minute.
The top of the standpipe must be at least 39”
(99 cm) high and no higher than 72” (183 cm)
from the bottom of the washer.
STANDPIPE DRAIN SYSTEM
Recessed front view Closet side view
closet
door
Front view
3" (7.6 cm)
3" (7.6 cm)
24"
2
(155 cm
2
)*
48"
2
(310 cm
2
)*
24"
2
(155 cm
2
)*
48"
2
(310 cm
2
)*
0"
(0 cm)
0"
(0 cm)
closet door
17"
(43.2 cm)
14"
(35.6 cm)
max.
4"
(10.2 cm)
min.
1" (2.5 cm)
min.
A
. 43" (109 cm)
B. 38 " (97 cm)
C. 35" (89 cm)
D. 1 " (3.8 cm)
E. 27 " (70.5 cm)
F. 25 " (65 cm)
G. Water inlets
H. 7" (18 cm)
I. Power supply cord
J. Drain hose connector
K. Label
L. 27" (68.5 cm)
M. 5 " (13.3 cm)
N. 1" (2.5 cm)
O. Water level switch and shaft
P. 5" (12.7 cm)

⁄
1
⁄
1
⁄
8

⁄

⁄
N
froid
chaud
A
B
C
E
D
F
G
I
J
O
H
P
K
L
M
H
Door opening cutouts
