4-39
The rear support leveling system is attached
to the base of the washer. The leg brackets
have a leveling spring in the middle. When
the rear of the washer is lifted and set back
down the weight of the washer causes the
legs to find the level position as they are
pushed up into the slots on the base.
1.
REAR SUPPORT LEVELING SYSTEM
Leveling
legs
Electrical Shock Hazard
Disconnect power before servicing.
Replace all parts and panels before
operating.
Failure to do so can result in death or
electrical shock.
