Maytag MAT14CS - Remove the Tub Ring

4-24
REMOVE THE TUB RING
Remove entire cabinet (see page 4-17).
Hang the console over the back edge of the
feature panel. Be sure that the wires pass
over the rolled top edge of the feature panel
to avoid damage to the wires.
1.
2.
Remove the clamp that secures the inlet
hose to the direct inject fill section of the tub
ring. Pull the hose off the inlet connection.
3.
Inlet hose clamp
Remove the tub ring by pressing down on
the ring and pulling the tabs away from the
tub to release the tabs all around the tub
ring.
4.
Lift the tub ring up off the tub. 5.
Inspect the tub ring gasket around the under
side of the tub ring for wear or damage.
Replace as needed.
6.
Tub ring tabs
Tub ring gasket
Electrical Shock Hazard
Disconnect power before servicing.
Replace all parts and panels before
operating.
Failure to do so can result in death or
electrical shock.
