Maytag MAT14CS - Replace Control Panel - MN Model

4-5
Remove the control panel (see page 4-1).
Remove the timer knob (see page 4-3).
Remove the escutcheon (see page 4-3).
Remove the controls (see page 4-4).
Remove the ground wire clip.
Replace the control panel.
1.
2.
3.
4.
5.
6.
REPLACE CONTROL
PANEL - MN MODEL
Electrical Shock Hazard
Disconnect power before servicing.
Replace all parts and panels before
operating.
Failure to do so can result in death or
electrical shock.
Ground
wire clip
