Maytag MAT14CS - Remove the Balance Ring - MN Model

4-26
The Balance ring is secured to the tub with
pressure tabs and stepped teeth that are
held with notches on the edge of the basket
Press on the finger tabs of the balance ring
to pull them away from the basket. Then lift
on the balance ring to remove it.
1.
2.
REMOVE THE BALANCE RING - MN MODEL
Electrical Shock Hazard
Disconnect power before servicing.
Replace all parts and panels before
operating.
Failure to do so can result in death or
electrical shock.
When replacing the balance ring set the ring
on the basket.
Press on the retaining fingers of the balance
ring to get it to drop into place.
Rotate the balance ring clockwise until the
teeth click onto the balance ring notches at
least 2 to 3 clicks.
3.
4.
5.
Basket-
notch
Stepped
teeth
Finger tab
