4-16
REMOVE THE CABINET FRONT
T-20 screws
To remove the cabinet front, remove the two
T-20 security screws from the lower edge of
the front panel.
1.
Remove the front panel by pulling out at the
bottom and down to release the clips at the
top edge of the front panel from the top of
the washer
2.
Clip
Electrical Shock Hazard
Disconnect power before servicing.
Replace all parts and panels before
operating.
Failure to do so can result in death or
electrical shock.
