Memotec CX950 User Manual

14 TOKEN RING LAN I/O CARD
3021M100-002
14-3
14.2 Token Ring Port Signal Handling
The following table describes the signal to pin relationships for both the DB-9 and
RJ-45 connectors.
14.3 Token Ring I/O Card Power Consumption
The power consumption is 5 Watts (17 BTU/hr).
Table 14-1 Token Ring Port Signal Handling
Signal
DB-9
Pin No.
Signal
RJ-45
Pin No.
RCV+ 1 not connected 1
not connected 2 not connected 2
not connected 3 XMT- 3
not connected 4 RCV+ 4
XMT+ 5 RCV- 5
RCV- 6 XMT+ 6
not connected 7 not connected 7
not connected 8 not connected 8
XMT- 9
