8.5 Voice SLIM LID Connector Pin Assignments
The following tables describe the signal outputs for North America and Europe
for the 6-pin RJ-12 connector and the 8-pin RJ-45 connectors.
8.6 Voice I/O Cables
The DAV I/O card connects to external devices through one of the following
separately-ordered cables:
• three meter (10 ft) straight-through cable with a male RJ-12 connector at each end
(part no. 60300049; used with FXS and FXO).
• three meter (10 ft) straight-through cable with a male RJ-45 connector at each end
(part no. 60300050; used with E&M types I through V voice interfaces).
• one-meter (40 in) octopus cable with six male RJ-45 connectors (each supporting eight
signals) at one end for connection to voice ports, and forming a single cable at the
other end with a standard 25-pair telco female connector (part no. 60300052; used to
connect to PBX punch block with E&M types I through V voice interfaces).
Table 8-4 Voice Connector Signal Output (RJ-12)
6-pin North American European
1 E E
2T1 RxA
3R TxB
4T TxA
5R1 RxB
6M M
Table 8-5 Voice Connector Signal Output (RJ-45)
8-pin North American European
1 M M
2E E
3T1 RxA
4R TxB
5T TxA
6R1 RxB
7SG SG
8SB SB
