CX950 Hardware Reference Manual
2-2
3021M100-002
• Token Ring LAN I/O
*The DDVC card provides voice compression and is not considered an I/O card,
although it occupies an I/O card slot. It must be installed with an ISDN-S/T I/O
Card to provide compressed voice capability to the CX950.
2.1 Specification
Consider the characteristics below when choosing an installation site for
CX950.
2.1.1 Physical
The CX950 is a standalone, tabletop device with an internal power supply. It is
enclosed in a steel case and mounted on four rubber supports.
WARNING:
Rubber supports must be secured to the chassis bottom at all times.
Failure to ensure minimum clearance will reduce ventilation and may
result in overheating of the unit.
Dimensions
Height: 4.10 in. (10.4 cm)
Width:12.25 in. (31.2 cm)
Depth:12.80 in. (32.5 cm)
2.1.2 Electrical
Ratings
Universal Input Detection 85-264 VAC; 50-60 Hz; 0.8-1.4A
Fuse
Requirements
1.6A 250V time-delay fuse for 85-264 VAC
WARNING:
This equipment uses double pole/neutral fusing. For continued protec-
tion against risk of fire, replace only with the same type and rating of
fuses.
Power
Requirements
160 VA (max.)
