CX950 Hardware Reference Manual
18-6
3021M100-002
Recall that a maximum of three (3) DIM I/O cards are permitted in the CX950: up
to three (3) may be used for unchannelized data and only one (1) may be used for
voice and/or channelized data.
18.3 RJ-45 Connector Pin-outs
Table 18-4 lists the pin assignments for the RJ-45 faceplate connector.
18.4 Power Requirements
18.4.1 Power Supply
The DIM is completely powered by the 5V source from the motherboard. The 5V
source supplies the 3.3V switching regulator and the 5V analog power filter. Th
3.3V source supplies the 2.5V regulator.
18.4.2 Power Consumption
The power consumption is 5 watts for channelized applications and 2 watts fo
unchannelized applications.
Table 18-4 RJ-45 Connector Pin-out
Pin Signal
1 Rx Tip
2Rx Ring
3unused
4Tx Tip
5Tx Ring
6unused
7unused
8unused
