CX950 Hardware Reference Manual
2-4
3021M100-002
Stop Bits: 1 bit/character
Parity: None
Speed: 9600 bps
Power Entry
The rear panel has a power entry module through which power enters the CX950
and goes to the power supply unit.
The power entry module consists of:
• a male connector for a standard IEC three-lead power cord
• a bank of fuses (1.6A 250V time-delay fuses) accessed with a screwdriver
WARNING:
This equipment uses double pole/neutral fusing. For continued protec-
tion against risk of fire, replace only with the same type and rating of
fuses.
