Any measure area can be renamed individually in the Name field. Under the field Shape the
different measuring shapes can be selected. The table above shows the available shapes.
The temperature of the main measuring area can also be displayed in the main window. The
value, which is displayed, is defined over the Minimum, Maximum, Mean value or Dis-
tribution [%] in the field Mode or via the icon in the toolbar.
Minimum Min. value is shown.
Maximum Max. value is shown.
Mean value Mean value is shown.
Distribution [%] Indicates the percentage distribution between two selected temperatures.
In the Position section the exact Location and Size of the measure area within the main window can be
defined. The moving and minimizing or maximizing of the measuring fields can also be realized directly at the
measuring field in the main window. By moving the cursor to the edges of the measuring field, the grippers
can be used to adjust the size of thermal image or to move the image completely (hold Ctrl synchronously).
If desired the area can represent a Hot spot (spot or area with highest mean temperature in the image) or
a Cold spot (spot or area with lowest mean temperature in the image).
Using Center you will be moving the measure area into the middle of the main window, using Standard
size the rectangle will be set in a predefined size. Under Label in image, you can select whether the
Name, Mode and / or Value is to be displayed in the image. Two-lines means that the selected labels are
displayed one after the other.
Using Bind to temperature profile you can assign each measure area to one of the two temperature
profile (Profile 1 / Profile 2).
The position of the measure area and the profile can be determined by the option Location [%]. The size
ratio can be defined by the option Min. Size.
