Control elements of the temperature axis
6 Global scaling: The temperature range of the diagram will automatically be adapted to the respective
peak values. The range will remain as set during the whole measurement.
7 Local scaling: The temperature range of the diagram will be adapted dynamically to the respective
peak values. After the respective peak has left the diagram in the further process of the measurement,
the range will be readapted. This option enables an optimum display of the temperature graph.
8 Scroll bar to choose temperature segment.
9 Zoom (increase) into the diagram. The time axis will remain.
10 Zoom (decrease) into the diagram. The time axis will remain.
11 Whole range: Display of whole temperature range which is set in the camera.
