MINI Hawk High Performance Imager User’s Manual A-11
Appendices
Delete Master Symbol Data <K231,master symbol number,>
Match Replace <K735,status,match replacement string>
Mismatch Replace <K736,status,mismatch replacement string>
Camera and IP Setup
Mirrored Image <K514,mirrored image>
Window of Interest
<
K516,
row pointer,column pointer,row depth,column width>
Focal Distance
<K525,focal distance>
Increment Focus Position
<525+>
Decrement Focus Position
<525–>
Focal Distance Table (Read-Only)
<K526,number of focal distances,focal distance>
Illumination Brightness <K536,brightness>
Camera <K541,shutter speed,gain>
Pixel Sub-Sampling <K542,
pixel sub-sampling,AEC/AGC mode,AEC/AGC brightness
>
Morphological Pre-Processing <K550,morphological pre-processing>
Morphological Operation <K551,0,morphological operation,operator size>
Configuration Database
Number of Active Indexes <K252,number of active database settings,database sort>
Configuration Database Status
<
K255,
index,shutter speed,gain,focal distance,pixel sub-sampling,
row pointer, column pointer,row depth,column width,narrow margins,
background color,symbology>
Save Current Settings to Database <K255+,index>
Load Current Settings from Database
<K255-,index>
Request Selected Index Settings <K255?,index>
Request All Database Settings <K255?>
Database Mode
<
K256,
switch mode,frame count/time,image process looping,image
dimensions>
Output Format
Format Extract <K740,output index,start location,length>
Format Insert <K741,output index,length,hex string>
Format Assign <K742,symbol number,status>
Format Status <K743,output format status>
Output Filter Configuration <K744,filter number,symbology,length,wildcard,placeholder,
data,unused,database index>
Ordered Output Filter <K745,number of filters>
