A-10 MINI Hawk High Performance Imager User’s Manual
Communication Protocol Commands
Image Output <K739,image output mode,communication port,file format,JPEG
quality>
Target/Flood LEDs <K750,green flash LED status,target pattern LED status,green
flash duration>
EZ Trax Output
<K757,comm port,image mode,image format,JPEG quality,
object info output,grade output>
Database Identifier Output <K759,status,separator>
EZ Button <K770,global status,default on power-on,load Configuration
Database,save for power-on>
EZ Button Modes <K771,single beep,two beeps,three beeps,four beeps>
Trend Analysis Output 1 <K780,trend analysis mode,trigger evaluation period,number to
output
on,decodes per trigger threshold>
Trend Analysis Output 2 <K781,trend analysis mode,trigger evaluation period,number to
output
on
,decodes per trigger threshold>
Trend Analysis Output 3 <K782,trend analysis mode,trigger evaluation period,number to
output
on,decodes per trigger threshold>
Diagnostic Output 1 <K790,unused 1,service unit>
Diagnostic Output 2 <K791,unused 1,service unit>
Diagnostic Output 3 <K792,unused 1,service unit>
ISO/IEC 16022 Symbol Quality Output 1
<
K800,
output on symbol contrast,symbol contrast threshold,output
on print growth,print growth threshold,output on axial non-uniformity
,
axial non-uniformity threshold,output on UEC,UEC threshold>
ISO/IEC 16022 Symbol Quality Output 2
<
K801,
output on symbol contrast,symbol contrast threshold,output
on print growth,print growth threshold,output on axial non-uniformity
,
axial non-uniformity threshold,output on UEC,UEC threshold>
ISO/IEC 16022 Symbol Quality Output 3
<
K802,
output on symbol contrast,symbol contrast threshold,output
on print growth,print growth threshold,output on axial non-uniformity
,
axial non-uniformity threshold,output on UEC,UEC threshold>
Configurable Output 1 <K810,output on,output state,pulse width,output mode>
Configurable Output 2 <K811,output on,output state,pulse width,output mode>
Configurable Output 3 <K812,output on,output state,pulse width,output mode>
Symbol Quality
Symbol Quality Separator/ Data Matrix
Output Mode
<K708,symbol quality separator,data matrix output mode>
ISO/IEC 16022 Symbol Quality Output
<
K709,
symbol contrast,print growth,axial non-uniformity,UEC>
Microscan Symbol Quality Output
<K710,percent cell damage,total read time,capture time,locate
time,decode time,pixels per element,ECC level,matrix size,quiet
zone>
Static Validation Report <VAL>
Matchcode
Matchcode Type
<
K223,
matchcode type,sequential matching,match start position,match
length,wild card character,sequence on No Read,sequence on
mismatch
>
Number of Master Symbols <K224,number of master symbols>
New Master Pin <K225,status>
Enter Master Symbol Data <K231,master symbol number,master symbol data>
Request Master Symbol Data
<
K231?,
>[for all]
or
<
K231?,
master symbol number>
