About vacuum table
1-8
About tap position
The table and the vacuum table on which the media set have the M4 tap (for 12 positions) of the size below
respectively.
12-M4
1002001003515
176.8 150
Origin
26.8
15
15 35 50 50 130 85 15
• UJF-3042HG
• UJF-6042
24-M4
150155155176.8 26.8
20
Origin
