1-9
1
Before Use
Notes on vacuum table
When you use the jig (vacuum table), the size shall be smaller than UJF-3042HG: 420 / UJF-6042: 720
millimeters wide and 505 millimeters long.
If you make the size be more than above, the table cannot move.
505mm
420mm
505mm
720mm
• UJF-3042HG
• UJF-6042
