1-14
Menu mode
This machine has three modes. Each mode is described below.
Local Mode
Local mode is a mode in drawing preparation state.
All keys are available.
Receiving of data from the computer is allowed, however, drawing is not executed.
The following operations are allowed in the local mode.
(1) Setting an origin and the table height by pressing the JOG keys.
(2) Executing “Test drawing” by pressing the key.
(3) Executing “head cleaning” by pressing the key.
(4) Execute setting of each function by pressing the key.
Function Mode
Press the key during the Local Mode to call the Function Mode.
Function settings on drawing method can be set.
Remote Mode
Remote mode is a mode in drawing received data.
Pressing of the key suspends the machine.
Press the during the Local Mode to switch to the Remote Mode.
