MIMAKI UJF-3042HG User Manual

Changing origin
3-3
3
Useful Function
Changing origin with FUNCTION menu
To precisely set the origin of coordinates, set its X- and Y- coordinates from the FUNCTION menu. This setting
value becomes the origin position (0, 0).
1
Press the key in the local mode.
2
Select the [ORIGIN] by pressing the or key,
and press the key twice.
• X-axis offset value setting screen is displayed.
3
Input value by pressing the
or keys, and press the key.
• Setting the origin position of X-axis.
• The value in the parentheses indicates the distance from the origin to the maximum effective area.
4
Select the [Y OFFS] by pressing the or keys,
and press the key.
5
Input value by pressing the or keys, and
press the key.
• Setting the origin position of Y-axis.
• The value on the first line indicates the distance from the origin to the maximum effective range.
6
Press the key several times to end the setting.
• The set value remains even if turning off the power.
<LOCAL>
FUNCTION
FUNCT I ON
SET OR I G I N <ENT>
ENTER
OR I G I N 4 1 0mm
XOFFS: 10mm
ENTER
OR I G I N
SELECT : Y OFFS
ENTER
OR I G I N 2 9 0mm
YOFFS: 10mm
ENTER
END
