Setting the Head Height
3-8
Gap check
Select operation when obstacles are detected during drawing.
1
Press the key in the local mode.
2
Select the [HEAD HEIGHT] by pressing the or
key, and press the key.
3
Select the [GAP CHECK] by pressing the or
keys, and press the key.
4
Select the mode by pressing the or keys, and
press the key.
• Set value: ON, OFF
• When ON is selected:
Before drawing, the work height is checked with the specified table height (media thickness).
Before and during drawing, if the work sensor is shielded, the table is lowered until it is unshielded to
change the table height.
If the work sensor is shielded when the table is lowered to the bottom, a message of [WORK High]
appears and the operation stops.
• When OFF is selected:
Before drawing, the work height is checked with the specified table height (media thickness), and if the
work sensor is shielded, a message of [WORK High] appears and the operation stops.
5
Press the key several times to end the setting.
• The gap check function is not a function to avoid the head hit completely by detecting obstacles. Even
when the GAP CHECK is “ON”, be sure to check the work height visually before drawing.
