Product Specifications
A-6
A.3.3 Battery
Size 147.5×60.4×23.8 mm
Weight 350 g
Number of batteries 2
Battery Type Chargeable Lithium-Ion
Voltage 11.1 VDC
Capacity 4500 mAh
2 h
Run time
2 new, fully charged batteries at 25
o
C under typical (with SpO
2
sensor but no ECG, Temp and IBP cables connected, and auto
NIBP measurements at intervals of 15 minutes) conditions
Charge time 6 h at most (in standby mode)
Shutdown delay 10 to 15 min (after a low battery alarm first occurs)
A.3.4 LEDs
Physiological alarm lamp 1 (two color coded: yellow and red)
Technical alarm lamp 1 (blue)
Power on LED 1 (green)
AC power LED 1 (green)
Battery LED 1 (green)
A.3.5 Audio Indicator
Speaker
Give alarm tones, key tones, QRS tones; support PITCH TONE
and multi-level tone modulation; alarm tones comply with
IEC60601-1-8.
