Product Specifications
A-7
A.3.6 Monitor Interface Specifications
Power 1 AC power input connector
2
Wire network
RJ45 connector, 100-Base-TX, IEEE 802.3
USB 10 connectors, USB 1.1
SMR connector 1 connector, not standard USB
CF 50-pin CF revision 2.0 connector
Video interface 1 connector, standard DVI-D
Auxiliary output
1 connector, standard BNC, the common connector of nurse call
signals and analog output signals
Equipotential Grounding
Terminal
1
Defib Sync Connector 1 connector, RJ11
A.3.7 Outputs
Auxiliary Output
Standard
Meets the requirements of EC60601-1 for short-circuit
protection and leakage current
Output impedance 50Ω rating
ECG Analog Output
Bandwidth
(-3dB; reference frequency:
10Hz)
Diagnostic mode:
Monitor mode:
Surgical mode:
0.05 to 100 Hz
0.5 to 40 Hz
1 to 20 Hz
Output signal range -2.5 to 2.5 V
Max transmission delay 25 ms (in diagnostic mode, and with Notch off)
Sensitivity 1V/mV ±5%
PACE rejection/enhancement No pace rejection or enhancement
IBP Analog Output
Bandwidth (-3dB; reference
frequency:1Hz)
0 to 12.5 Hz
Max transmission delay 55 ms (with Notch off)
Sensitivity 1 V/100 mmHg ±5%
Nurse Call Signal
