Product Specifications
A-11
A.5.2 Resp
Technique Trans-thoracic impedance
Lead Options are lead I and II. The default is lead II.
Excitation current <300 µA
Respiration impedance range 0.3 to 5Ω
Baseline impedance range 200 to 2500Ω (using an ECG cable with 1kΩ resistance)
Differential input impedance >2.5 MΩ
Bandwidth 0.2 to 2 Hz (-3 dB)
Sweep speed 6.25, 12.5 or 25 mm/s
Respiration Rate
Measurement range
Adult:
Pediatric, neonate:
0 to 120 rpm
0 to 150 rpm
Resolution 1 rpm
Accuracy
7 to 150 rpm:
0 to 6 rpm:
±2 rpm or ±2%, whichever is greater
Not specified.
Apnea alarm time 10 s, 15 s, 20 s, 25 s, 30 s, 35 s, 40 s
