Display & Cine Review 7-9
h Parameters that can result in imaging region or direction changing, such as
depth, FOV, trapezoid, steer, zoom and so on.
h Parameters that can result in image frame changing, such as line density,
focus number and so on.
h Change ROI position and size.
h Change speed in M/D mode, or change the scale in PW mode.
h 2D image cleared/
z Unfreeze the image: after the image is unfrozen, images stored in the cine
memory will be cleared, but if the cine memory is split, only the currently cine
memory corresponding to the activated window will be cleared.
z Open/ close the image file that occupies cine memory.
7.7 Cine Settings
You can set the cine length via “[Setup] [System Preset] [General]”. The items are
shown as follows:
Non-live storage (the items are shown as follows)
z
For Time without ECG(s), 1~60s.
z For Time (with ECG Loop): the unit is Beat, 1~16.
Live capture (the setting items are shown as follows)
z Type: Retrospective, Prospective.
z Cine length:
