Mindray DC-T6 User Manual

6-12 Stress Echo
6.7.2 Protocol Edit
You can create, edit, and delete Stress Echo protocols using the Protocol Editor dialog
box. Your changes will display in the Select Protocol to Load window the next time you
activate the Stress Echo feature.
Access the Protocol Editor dialog box by clicking [Protocol Editor] on the Select Protocol
screen. As shown in the figure below:
Item Function Description
Protocol name Enter the protocol name.
Stage Set stages for the protocol.
Trigger Set the trigger type.
WMS model Set the methods of chamber segments division.
Loop usage
Displays the acquired loop number as well as the total usable loop
number.
View Set the views for the each stage.
Standard views Set the standard view.
Import Import a protocol.
Export Export a protocol.
New Create a new protocol.
Load Load an existing protocol.
Save Save the change (s) for the protocol.
Delete Delete the protocol.
Quit To remove the Protocol Editor dialogue box.
Creating a Stress Echo Protocol
To create a stress echo protocol:

Mindray DC-T6 Specifications

General

Brand	Mindray
Model	DC-T6
Category	Medical Equipment
Language	English
