System Preparation 3-17
5. If it is a digital color video printer, connect the power cable and USB cable to the
system.
Operations of adding/modifying print service is same as the operations of the B/W video
printer, please refer to it.
Please refer to the accompanying manuals of the printers for more details.
3.7.5 Installing the Barcode Reader
Directly insert the USB port of the barcode reader to the system applicable USB ports.
Please refer to “Appendix C Barcode Reader” for operations of the barcode reader.
3.8 Basic Screen and Operation
3.8.1 Basic Screen
The following diagram maps out the different areas in the screen:
Logo
Hospital Name
Exam
Time
Acoustic
Power
MI/TI
Accession#
Freeze
icon
Patient Information Probe
Exam
Mode
Operator
ECG
icon
Parameter and
Menu Area
Image area
Thumbnail Area of
Images Stored
Image-in-image
Thumbnail
Cine Review
Body Mark Area
Help information area Cursor area
Soft Menu Area System status icon
Information Area
The information area displays manufacturer logo, hospital name, exam date & time,
acoustic power & MI/TI, freeze icon, patient information, probe model, current exam
mode, ECG icon (if ECG module is configured), and accession #, etc.
