15-16 Setup
Available tools are described as follows:
b) Check on the screen, move the cursor onto the probe mark and
press <Set>, adjust the position with the trackball and direction with the
multifunctional knob.
c) After the drawing of a body mark is completed, click [OK] to save it and exit
the user-defined body mark status.
îš„ Edit/ delete a user-defined body mark
After selecting a user-defined body mark, click the [Edit] button to edit it.
îš„ Delete
After selecting a user-defined body mark, click [Delete] to delete the selected image.
îš„ Load:
Click [Load] to load user-defined body mark from external media.
îš„ Export
Click [Export] to export user-defined body mark to external media.
îš„ Return
Click [Return] to exit the current screen.
Left/right flip Up/down flip
Brush Eraser
Zoom in Zoom out
Rotate Drag
