14. Transportation
MiR250 Hook Integrator Manual (en) 12/2023 - v.3.0 ©Copyright 2021–2023: Mobile Industrial Robots A/S. 182
3 Mount the four M8 × 16 mm eye bolts that came with the robot to the mounting holes.
Make sure to screw the eye bolts all the way in. Do not tighten the bolts over 7.5 Nm.
The eye bolts should be oriented in parallel to the opposite diagonal bolt to ensure
stable lifting.
4 Use an appropriate lifting device to lift the robot. The lifting device should be capable of
lifting at least 400 kg.
