Mitsubishi F700 Series User Manual

1
3
4
5
6
7
1
2
1 OUTLINE
This chapter describes the basic "OUTLINE" for use of this
product.
Always read the instructions before using the equipment.
1.1 Product checking and parts identification ............... 2
1.2 Inverter and peripheral devices .............................. 3
1.3 Method of removal and reinstallation of the front
cover....................................................................... 5
1.4 Installation of the inverter and enclosure design .... 7
<Abbreviations>
DU ............................................Operation panel (FR-DU07)
PU.................................................. Operation panel (FR-DU07) and parameter unit (FR-PU04/FR-
PU07(-01))
Inverter .....................................Mitsubishi inverter FR-F700 series
FR-F700 ...................................Mitsubishi inverter FR-F700 series
Pr. .............................................Parameter Number (Number assigned to function)
PU operation ............................. Operation using the PU (FR-DU07/FR-PU04/FR-PU07(-01)).
External operation ....................Operation using the control circuit signals
Combined operation .................Combined operation using the PU (FR-DU07/FR-PU04/FR-
PU07(-01)) and external operation.
Mitsubishi standard motor ........SF-JR
Mitsubishi constant-torque motor ...SF-HRCA
<Trademarks>
• Microsoft and Visual C++ are registered trademarks of Microsoft Corporation in the United
States and/or other countries.
•L
ONWORKS
®
is a registered trademark of Echelon Corporation in the U.S.A and other
countries.
• DeviceNetTM is a registered trademark of ODVA (Open DeviceNet Vender Association,
Inc.).
• BACnet
®
is a registered trademark of American Society of Heating, Refrigerating and
Air-Conditioning Engineers (ASHRAE).
• Other company and product names herein are the trademarks and registered trademarks of
their respective owners.

Mitsubishi F700 Series Specifications

General

Humidity	95% RH or less (non-condensing)
Control Method	V/F control
Protection Features	Overcurrent, overvoltage, undervoltage, overheat, short circuit
Communication Options	RS-485
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Altitude	Up to 1000m above sea level
Overload Capacity	150% for 60 seconds
Cooling Method	Forced air cooling
Power Range	0.75 to 630 kW (1 to 845 hp)
Output Voltage	3-phase 200 to 240 VAC, 380 to 500 VAC (matching input voltage)
