Mitsubishi F700 Series User Manual

311
Setting from the parameter unit, operation panel
4
PARAMETERS
4.23 Setting from the parameter unit, operation panel
4.23.1 PU display language selection (Pr. 145)
* Depending on the parameter unit, some parameter names or fault names etc. may not be displayed at all, or only displayed in English.
The above parameters can be set when Pr. 160 User group read selection = "0". (Refer to page 185.)
4.23.2 Setting dial potentiometer mode/key lock selection (Pr. 161)
The above parameters can be set when Pr. 160 User group read selection = "0". (Refer to page 185.)
Purpose Parameter that must be Set
Refer to
Page
Switch the display language of the
parameter unit
PU display language
selection
Pr. 145 311
Use the setting dial of the operation
panel like a potentiometer for frequency
setting.
Key lock of operation panel
Operation panel operation
selection
Pr. 161 311
Control of the parameter unit, operation
panel buzzer
PU buzzer control Pr. 990 313
Adjust the LCD contrast of the parameter
unit
PU contrast adjustment Pr. 991 313
The display language of the parameter unit (FR-PU04/FR-PU07) can be changed to other languages.
Parameter
Number
Name Initial Value Setting Range Definition *
145 PU display language selection 1
0 Japanese
1 English
2 Germany
3 French
4 Spanish
5Italian
6 Swedish
7Finnish
The setting dial of the operation panel (FR-DU07) can be used like a potentiometer to perform operation.
The key operation of the operation panel can be disabled.
Parameter
Number
Name Initial Value
Setting
Range
Description
161
Frequency setting/key lock
operation selection
0
0
Setting dial frequency
setting mode
Key lock invalid
1
Setting dial potentiometer
mode
10
Setting dial frequency
setting mode
Key lock valid
11
Setting dial potentiometer
mode

Mitsubishi F700 Series Specifications

General

Humidity	95% RH or less (non-condensing)
Control Method	V/F control
Protection Features	Overcurrent, overvoltage, undervoltage, overheat, short circuit
Communication Options	RS-485
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Altitude	Up to 1000m above sea level
Overload Capacity	150% for 60 seconds
Cooling Method	Forced air cooling
Power Range	0.75 to 630 kW (1 to 845 hp)
Output Voltage	3-phase 200 to 240 VAC, 380 to 500 VAC (matching input voltage)
