Parameter copy and parameter verification
4.27.2 Parameter verification
appears...Why? Parameter read error. Perform operation from step 3 again.
appears...Why? Parameter write error. Perform operation from step 8 again.
and flicker alternately
Appears when parameters are copied between the inverter of 01160 or less and 01800 or more.
1. Set "0" in Pr. 160 User group read selection.
2. Set the following setting (initial value) in Pr. 989 Parameter copy alarm release.
3. Reset Pr. 9, Pr. 30, Pr. 51, Pr. 52, Pr. 54, Pr. 56, Pr. 57, Pr. 70, Pr. 72, Pr. 80, Pr. 90, Pr. 158, Pr. 190 to Pr. 196, Pr. 557,
Pr. 893.
Whether same parameter values are set in other inverters or not can be checked.
REMARKS
When the copy destination inverter is not the FR-F700 series, "model error ( )" is displayed.
flickers ... Why?
Set frequencies, etc. may be different. Check set frequencies.
01160 or less 01800 or more
Pr. 989 Setting 10 100
• Hold down to verify.
2.Screen at powering ON
The monitor display appears.
Display
Operation
7.Press to read the parameter setting
of the verified inverter to the operation panel.
1.Move the operation panel to the
inverter to be verified.
• Move it during a stop.
Flicker ··· Parameter verification complete!!
4.Turn until (parameter copy)
appears.
6.Turn to change it to the set value
" "(parameter copy verification mode).
8.If there is no difference, and
flicker to complete verification.
The frequency flickers
for about 30s
Flickering
• If different parameters exist, different
parameter numbers and flicker.
The parameter
number read
previously appears.
5.Press to read the present set
value.
" "(initial value) appears.
3.Press to choose the parameter
setting mode.

Mitsubishi F700 Series Specifications

General

Humidity	95% RH or less (non-condensing)
Control Method	V/F control
Protection Features	Overcurrent, overvoltage, undervoltage, overheat, short circuit
Communication Options	RS-485
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Altitude	Up to 1000m above sea level
Overload Capacity	150% for 60 seconds
Cooling Method	Forced air cooling
Power Range	0.75 to 630 kW (1 to 845 hp)
Output Voltage	3-phase 200 to 240 VAC, 380 to 500 VAC (matching input voltage)
