383
For customers who are replacing the conventional model with this inverter
(4) Main differences and compatibilities with the FR-F500(L) series
Appendix 1-2 Replacement of the FR-A100 <EXCELENT> series
Instructions for installation
• When using the installation holes of the FR-A100(E) series, FR-A5AT (intercompatibility attachment) is necessary.
Item FR-F500(L) FR-F700
Changed functions
Simple mode
parameters
61 parameters
20 parameters
User group
User group 1 (16), user group 2 (16)
(Pr. 160, Pr. 173 to Pr. 175)
User group (16) only
Setting methods were partially changed
(Pr. 160, Pr. 172 to Pr. 173)
Communication
option
Performing the parameter clear or all parameter
clear (H5A96 or HAA99) from the DeviceNet
communication option (FR-A5ND) clears the Pr.
345 and Pr. 346 settings.
Performing the parameter clear or all parameter clear
(H5A96 or HAA99) from the DeviceNet communication
option (FR-A7ND) does not clear the Pr. 345 and Pr. 346
settings.
Advanced PID
(pump function)
Pr. 500 to Pr. 516
Parameter number change
Pr. 575 to Pr. 591
Changed
initial value
Pr. 0 Torque
boost
Initial value
11K to 55K: 2%
00250 to 00770: 2%, 00930, 01160: 1.5%
(When the torque boost value of the FR-F500 series
used was the initial value, it is not necessary to change
the torque boost value from the initial value when
replacing with the FR-F700 series.)
Deleted functions
User initial
value setting
(Pr. 199 )
Available
Not available
Substitutable with the copy function of the operation
panel (FR-DU07)
Intelligent
optimum
acceleration/
deceleration
Available
(Pr. 60 setting "3" and Pr. 61 to Pr. 63)
Not available
For deceleration time, overvoltage fault can be avoided
with regeneration avoidance function (Pr. 882 to Pr. 885).
Automatic
torque boost
Pr. 38, Pr. 39
Automatic torque boost was cleared because of addition
of "Simple magnetic flux vector" (Pr. 80)
Terminal block Removable terminal block
Removable terminal block
Upward compatibility (Terminal block of the F500 can be
mounted)
PU FR-PU04, DU04
FR-PU07
FR-DU07
FR-DU04 unavailable (Partly restricted when the FR-
PU04 is used. Refer to page 382.)
Plug-in option
Dedicated plug-in option (not compatible)
Computer link, relay output option
FR-A5NR
Built into the inverter
(RS-485 terminal, relay output 2 points)
Three boards can be mounted
Two board can be mounted
Installation size
00023 to 00083, 00170, 00470, 00770 to 01160 are compatible in mounting dimensions
For other capacities, an optional intercompatibility attachment (FR-AAT) is necessary.
To Next Page
