Mitsubishi F700 Series User Manual

56
Parameter list
4.2 Parameter list
4.2.1 Parameter list
In the initial setting, only the simple mode parameters are displayed.
Set Pr. 160 User group read selection as required.
Parameter Name
Initial
Value
Setting
Range
Remarks
160
User group read
selection
9999
9999 Only the simple mode parameters can be displayed.
0
Simple mode and extended mode parameters can be
displayed.
1
Only the parameters registered in the user group can be
displayed.
REMARKS
 The parameters marked  are the simple mode parameters.
 The parameters marked with in the table allow its setting to be changed during operation even if "0" (initial
value) is set in Pr. 77 Parameter write selection.
 Refer to the appendix 2 (page 384) for instruction codes for communication and availability of parameter clear, all clear, and
parameter copy of each parameter.
Function Parameters
Name Setting Range
Minimum
Setting
Increments
Initial
Value
Refer
to
Page
Customer
Setting
Basic functions
 0
Torque boost 0 to 30% 0.1%
6/4/3/2/
1.5/1%
*1
71
 1
Maximum frequency 0 to 120Hz 0.01Hz
120/60Hz
*2
80
 2
Minimum frequency 0 to 120Hz 0.01Hz 0Hz 80
 3
Base frequency 0 to 400Hz 0.01Hz 50Hz 82
 4
Multi-speed setting (high speed) 0 to 400Hz 0.01Hz 50Hz 86
 5
Multi-speed setting (middle speed) 0 to 400Hz 0.01Hz 30Hz 86
 6
Multi-speed setting (low speed) 0 to 400Hz 0.01Hz 10Hz 86
 7
Acceleration time 0 to 3600/ 360s 0.1/0.01s 5s/15s *3 94
 8
Deceleration time 0 to 3600/ 360s 0.1/0.01s 10s/30s *3 94
 9
Electronic thermal O/L relay 0 to 500/0 to 3600A 0.01/0.1A
Rated
inverter
current
100
DC injection
brake
10
DC injection brake operation
frequency
0 to 120Hz, 9999 0.01Hz 3Hz 106
11
DC injection brake operation time 0 to 10s, 8888 0.1s 0.5s 106
12
DC injection brake operation voltage 0 to 30% 0.1% 4/2/1% *4 106

13
Starting frequency 0 to 60Hz 0.01Hz 0.5Hz 97

14
Load pattern selection 0, 1 1 1 84
Jog
operation
15
Jog frequency 0 to 400Hz 0.01Hz 5Hz 88
16
Jog acceleration/deceleration time 0 to 3600/360s 0.1/0.01s 0.5s 88

17
MRS input selection 0, 2 1 0 119

18
High speed maximum frequency 120 to 400Hz 0.01Hz
120/60Hz
*2
80

19
Base frequency voltage 0 to 1000V, 8888, 9999 0.1V 8888 82

Mitsubishi F700 Series Specifications

General

Humidity	95% RH or less (non-condensing)
Control Method	V/F control
Protection Features	Overcurrent, overvoltage, undervoltage, overheat, short circuit
Communication Options	RS-485
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Altitude	Up to 1000m above sea level
Overload Capacity	150% for 60 seconds
Cooling Method	Forced air cooling
Power Range	0.75 to 630 kW (1 to 845 hp)
Output Voltage	3-phase 200 to 240 VAC, 380 to 500 VAC (matching input voltage)
