Mitsubishi F700 Series User Manual

15
Main circuit terminal specifications
2
WIRING
FR-F740-00310, 00380-EC FR-F740-00470, 00620-EC
FR-F740-00770 to 01160-EC FR-F740-01800 to 02600-EC
FR-F740-03250 to 04810-EC FR-F740-05470 to 12120-EC
R1/L11 S1/L21
R/L1 S/L2 T/L3
N/-
P/+
PR
Charge lamp
Jumper
Jumper
Power supply
IM
Motor
R/L1 S/L2 T/L3
N/-
P/+
PR
R1/L11 S1/L21
IM
Jumper
Jumper
Charge lamp
Power supply
Motor
IM
Jumper
Jumper
Charge lamp
Power
supply
Motor
R/L1 S/L2 T/L3
N/-
P/+
R1/L11 S1/L21
IM
R/L1 S/L2 T/L3
N/-
P/+
R1/L11 S1/L21
DC reactor
Power
supply
Motor
Jumper
Charge lamp
P/+
IM
R/L1 S/L2 T/L3
N/-
P/+
R1/L11 S1/L21
P/+
P/+
Jumper
Charge lamp
MotorPower supply
DC reactor
IM
R/L1 S/L2 T/L3
N/-
R1/L11 S1/L21
P/+
P/+
Jumper
Charge lamp
Motor
Power supply
DC reactor

Mitsubishi F700 Series Specifications

General

Humidity	95% RH or less (non-condensing)
Control Method	V/F control
Protection Features	Overcurrent, overvoltage, undervoltage, overheat, short circuit
Communication Options	RS-485
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Altitude	Up to 1000m above sea level
Overload Capacity	150% for 60 seconds
Cooling Method	Forced air cooling
Power Range	0.75 to 630 kW (1 to 845 hp)
Output Voltage	3-phase 200 to 240 VAC, 380 to 500 VAC (matching input voltage)
