Mitsubishi F700 Series - Page 262

251
Communication operation and setting
4
PARAMETERS
 Parameter
Parameters Register Parameter Name Read/Write Remarks
0 to 999
41000 to
41999
Refer to the parameter list (page
56) for the parameter names.
Read/write
The parameter number + 41000 is the
register number.
C2(902)
41902
Terminal 2 frequency setting
bias (frequency)
Read/write
C3(902)
42092
Terminal 2 frequency setting
bias (analog value)
Read/write
The analog value (%) set to C3 (902) is
read.
43902
Terminal 2 frequency setting
bias (terminal analog value)
Read
The analog value (%) of the voltage
(current) applied to the terminal 2 is read.
125(903)
41903
Terminal 2 frequency setting
gain (frequency)
Read/write
C4(903)
42093
Terminal 2 frequency setting
gain (analog value)
Read/write
The analog value (%) set to C4 (903) is
read.
43903
Terminal 2 frequency setting
gain (terminal analog value)
Read
The analog value (%) of the voltage
(current) applied to the terminal 2 is read.
C5(904)
41904
Terminal 4 frequency setting
bias (frequency)
Read/write
C6(904)
42094
Terminal 4 frequency setting
bias (analog value)
Read/write
The analog value (%) set to C6 (904) is
read.
43904
Terminal 4 frequency setting
bias (terminal analog value)
Read
The analog value (%) of the current
(voltage) applied to the terminal 4 is read.
126(905)
41905
Terminal 4 frequency setting
gain (frequency)
Read/write
C7(905)
42095
Terminal 4 frequency setting
gain (analog value)
Read/write
The analog value (%) set to C7 (905) is
read.
43905
Terminal 4 frequency setting
gain (terminal analog value)
Read
The analog value (%) of the current
(voltage) applied to the terminal 4 is read.
C8(930)
41930 Current output bias signal Read/write
C9(930)
42120 Current output bias current Read/write
C10(931)
41931 Current output gain signal Read/write
C11(931)
42121 Current output gain current Read/write
C42(934)
41934 PID display bias coefficient Read/write
C43(934)
42124 PID display bias analog value Read/write
The analog value (%) set to C43 (934) is
read.
43934
PID display bias analog value
(terminal analog value)
Read
The analog value (%) of the current
(voltage) applied to the terminal 4 is read.
C44(935)
41935 PID display gain coefficient Read/write
C45(935)
42125 PID display gain analog value Read/write
The analog value (%) set to C45 (935) is
read.
43935
PID display gain analog value
(terminal analog value)
Read
The analog value (%) of the current
(voltage) applied to the terminal 4 is read.
