Mitsubishi F700 Series User Manual

279
PID control
4
PARAMETERS
(2) System configuration
· Basic system (Pr. 579 = "0")
RST UVW
RT
10
2
5
1
4
FU
OL
IPF
SE
RO2
RO3
RO4
MC RO2
24VDC
0
24V
RO4
RO3
RO2
MC
M1
X64
STF
STR
JOG
X14
Power
supply
Inverter
Reverse rotation
Forward rotation
Advanced PID
control selection
action switching
PID forward-reverse
Setting potentiometer
(Set point setting)
Deviation signal
Supplied water
For 2-wire type
Detecto
r
When Pr. 183 = 14, Pr. 185 = 64,
Pr. 194 = 72, Pr. 193 = 73, Pr. 192 = 74
(Measured value) 4 to 20mA
Distributed water
Example
PUMP4
PUMP3
PUMP2
PUMP1
supply
Power
+
-
M4
M3
M2
MC RO4
MC RO3
Source logic
PC

Mitsubishi F700 Series Specifications

General

Humidity	95% RH or less (non-condensing)
Control Method	V/F control
Protection Features	Overcurrent, overvoltage, undervoltage, overheat, short circuit
Communication Options	RS-485
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Altitude	Up to 1000m above sea level
Overload Capacity	150% for 60 seconds
Cooling Method	Forced air cooling
Power Range	0.75 to 630 kW (1 to 845 hp)
Output Voltage	3-phase 200 to 240 VAC, 380 to 500 VAC (matching input voltage)
