Mitsubishi F700 Series User Manual

392
870
Speed detection hysteresis
46 C6 8
  
872
Input phase loss protection selection
48 C8 8
 
882
Regeneration avoidance operation
selection
52 D2 8
  
883
Regeneration avoidance operation level
53 D3 8
 
884
Regeneration avoidance at deceleration
detection sensitivity
54 D4 8
  
885
Regeneration avoidance compensation
frequency limit value
55 D5 8
 
886
Regeneration avoidance voltage gain
56 D6 8
  
888
Free parameter 1
58 D8 8


889
Free parameter 2
59 D9 8

 
891
Cumulative power monitor digit shifted
times
5B DB 8
 
892
Load factor
5C DC 8
  
893
Energy saving monitor reference (motor
capacity)
5D DD 8
 
894
Control selection during commercial
power-supply operation
5E DE 8
  
895
Power saving rate reference value
5F DF 8
 
896
Power unit cost
60 E0 8
  
897
Power saving monitor average time
61 E1 8
 
898
Power saving cumulative monitor clear
62 E2 8



899
Operation time rate (estimated value)
63 E3 8
 
C0
(900)
CA terminal calibration
5C DC 1



C1
(901)
AM terminal calibration
5D DD 1



C2
(902)
Terminal 2 frequency setting bias
frequency
5E DE 1



C3
(902)
Terminal 2 frequency setting bias
5E DE 1



125
(903)
Terminal 2 frequency setting gain
frequency
5F DF 1



C4
(903)
Terminal 2 frequency setting gain
5F DF 1



C5
(904)
Terminal 4 frequency setting bias
frequency
60 E0 1



C6
(904)
Terminal 4 frequency setting bias
60 E0 1



126
(905)
Terminal 4 frequency setting gain
frequency
61 E1 1



C7
(905)
Terminal 4 frequency setting gain
61 E1 1



C8
(930)
Current output bias signal
1E 9E 9
  
C9
(930)
Current output bias current
1E 9E 9
 
C10
(931)
Current output gain signal
1F 9F 9
  
C11
(931)
Current output gain current
1F 9F 9
 
C42
(934)
PID display bias coefficient
22 A2 9



C43
(934)
PID display bias analog value
22 A2 9



C44
(935)
PID display gain coefficient
23 A3 9



Parameter Name
Instruction Code *1
Parameter
Copy
*2
Parameter
Clear
*2
All Parameter
Clear
*2
Read Write Extended

Mitsubishi F700 Series Specifications

General

Humidity	95% RH or less (non-condensing)
Control Method	V/F control
Protection Features	Overcurrent, overvoltage, undervoltage, overheat, short circuit
Communication Options	RS-485
Operating Temperature	-10°C to +50°C
Storage Temperature	-20°C to +65°C
Altitude	Up to 1000m above sea level
Overload Capacity	150% for 60 seconds
Cooling Method	Forced air cooling
Power Range	0.75 to 630 kW (1 to 845 hp)
Output Voltage	3-phase 200 to 240 VAC, 380 to 500 VAC (matching input voltage)
